● Extinguisher cylinders have a phosphate under treatment to resist corrosion.
● External Epoxy Paint adds extra protection to with stand extreme temperatures.
● 100% cylinders must pass the hydraulic pressure test, without any leakage.
● Valve material: Brass
● Agent: 40% ABC dry powder(Monoammonium Phosphate) is capable of fighting class A. B. C & E Fires.
● The products are always exported to South America with stamp of
XXKG PT 14KG/cm2 PP 35KG/cm2
Month/Year xxxxxx (Serial number).
| Model: | FP-JS-03-01A | FP-JS-03-01B |  |
| High-Approx(mm): | 265 | 240 | |
| Shell-Approx Dia(mm): | 80 | 90 | |
| Cylinder Min Wall-thickness(mm): | 0.72 | 0.79 | |
| Volume: | 1.25L | 1.25L | |
| Material: | DC01 | DC01 | |
| Weight Full-Approx(kg): | 1.7 | 1.7 | |
| CTN size: | 49.5X29X35cm/12PCS | 49X20.5X33cm/10PCS | |
| Max working Pressure/Test Pressure(Bar): | 16/25 | 16/25 |
